Pacific Tundra

Infrared Heat Panel - Portable - 4800 Watts 240 Volts - 20 Amp - Cure Clear Coat

Infrared Heat Panel - Portable - 4800 Watts 240 Volts - 20 Amp - Cure Clear Coat

Regular price $4,312.22
Regular price Sale price $4,312.22
Sale Sold out
start_elivehelp_btncode
end_elivehelp_btncode




FREE SHIPPING OFFER

Free Shipping within the Lower 48 United States. If you are located outside of the Lower 48 United States, please request a freight quote.




Model Number:


PTWBB202352


Condition:


New


Description:


Infrared Heat Panel - Portable - 4800 Watts 240 Volts - 20 Amps - Commercial


Features:



This Commercial-Duty, High Intensity Heat Panel is ideal for curing coatings and adhersives, laminating, thermoforming, heat shrinking and drying. Panel is built to withstand rigors of industrial and heavy commercial applications including auto collision repair shops. Made using 20 gauge steel frame, base and housing. Gold anodized aluminum reflectors and end caps allow 10% faster cure time over polished aluminum reflectors. Adjustable hinges allow the user to direct heat to the target area. Heating elements achieve full temperature in less than 2 minutes and are rated for an average life of 5,000 hours. Includes 20'L type SO cable and fused disconnect switches on rear. Features high temperature 200°C rated wiring. Wide steel base includes heavy duty 3" steel casters for high stability and ease of mobility. 240 Volts. 1 Year Limited Warranty.




Contact Us:


Phone (Toll Free): .







PLEASE NOTE THE BELOW INFORMATION

This unit is built to order and will require 10 to 14 Business Days to manufacture.

Please contact us for current lead times or for any additional assistance.

We offer various specifications for this heater.
If you cannot find what you are looking for, please contact us for assistance.



Description & Specification:

LENGTH INCHES: 10

WIDTH INCHES: 44 3/4

HEIGHT INCHES: 56 1/2

COLOR: Gold

CONSTRUCTION: 20GA Steel

VOLTAGE: 240

AMPS: 20

WATTS: 4800

KILOWATTS: 4.8

POWER CORD TYPE: S/O Cable

FOR USE WITH: 4 1200w elements

LIMITED WARRANTY YEARS: 1

Built to withstand rigors of industrial and heavy-commercial applications, such as auto collision repair shops.

20 gauge steel frame, base, and housing construction.

Wide steel base with heavy-duty 3” steel casters for high stability and ease of mobility.

Gold anodized aluminum reflectors and end caps allow 10% faster cure time than
polished aluminum reflectors, especially in paint and dust-laden atmospheres.

Elements achieve full temperature in less than 1 to 2 minutes.

Heating elements are rated for an average life expectancy of 5,000 hours.

20’ of Type SO cable standard with each unit.

Fused disconnect switches installed on the back of each unit.

All internal wiring consists of high-temp 200ºC rated wire.

Units are easily positioned with adjustable hinges allowing the user to direct heat
precisely to the target area.

Gentle but effective medium-wave radiant heat can quickly boost, flash-off, or cure a variety of finishes, and lessens the chance of blistering and/or overheating the coating.

Medium-wave infrared heating elements are also effective for flash-off of water-based clear coatings being mandated by environmental agencies in many states.
