Infrared Natural Gas Heater - 40,000 BTU - 120 Volts - Aluminum Reflectors

Free Shipping within the Lower 48 United States. If you are located outside of the Lower 48 United States, please request a freight quote.

Model Number: PT1117

Condition: New

Description: Infrared Natural Gas Heater - 40,000 BTU - 120 Volts - Commercial

Description & Specification:

Constructed from aluminized steel for corrosion-resistance

Aluminum reflectors are designed to maximize radiant output

Units are equipped with 100% gas shut-off safety control

Dimpled tile assembly design for increased radiant efficiency

Design certified for angle mounting up to 30 degrees

Indirect vented operation

Includes a 120 Volt thermostat

Thermostat Specifications:

Requires 4CFM per 1000 BTU/hr of mechanical ventilation of the total installed capacity

Read installation and operating instructions prior to purchase

Not certified or approved for residential use.

Type: Infrared

Fuel Source: Natural Gas

BTU: 40,000

Volts: 120

Amps: 0.4

Phase: Single

Ignition: Direct Spark

Material: Aluminized Steel / Aluminum

Burner Pressure (in): 6"

Number of Burners: 1

Min Clearance Combustibles at Horizontal: Sides 31, Ceiling 37, Below 73 in

Min Clearance Combustible at 30° Angle: Front 37, Rear 31, Below 73 in

Please Note: This item is built to order. Please allow 10 Business Days for manufacturing and handling

Please Note: The photos associated with this listing are stock photos. Actual burner quantity will be indicated here in the description - Please thoroughly review this information prior to purchasing.

Dimensions (W x D x H): 26.5" x 17-3/4" x 14"

Weight (lbs): 45
